7/16 DIN Terminations
7/16 DIN Terminations are high-performance RF loads designed to absorb RF signal power and eliminate unwanted reflections in transmission lines. They provide accurate 50 Ohm impedance matching, protecting RF equipment while ensuring excellent signal integrity and stable system performance. These terminations are extensively used in cellular base stations, Distributed Antenna Systems (DAS), telecom infrastructure, broadcasting, RF testing, microwave communication, and industrial wireless networks. Due to the rugged 7/16 DIN interface, they offer outstanding power handling capability, low passive intermodulation (Low PIM), and reliable outdoor performance.
At SRFS Teleinfra, we manufacture premium-quality 7/16 DIN Terminations using precision machining, premium-grade brass and stainless steel, silver or gold-plated contacts, and high-quality dielectric materials. Our RF terminations deliver excellent return loss, low VSWR, superior durability, and dependable long-term performance in demanding RF environments.
Every 7/16 DIN Termination is manufactured in India under stringent quality control procedures and undergoes comprehensive electrical and mechanical testing to ensure reliable operation for telecom operators, defense organizations, broadcast networks, wireless communication systems, and RF laboratories.
What is a 7/16 DIN Termination?
A 7/16 DIN Termination is a passive RF component that safely absorbs RF energy from unused RF ports while maintaining a constant 50 Ohm impedance. It prevents signal reflections, protects valuable RF equipment, and improves the overall performance of RF and microwave systems.
The 7/16 DIN connector is widely recognized for its excellent power handling capability, low passive intermodulation (PIM), rugged threaded coupling mechanism, and reliable outdoor performance, making it a preferred choice for cellular base stations, DAS installations, and high-power RF systems.
Technical Specifications of 2.4mm Attenuators
Our 7/16 DIN Terminations are designed to deliver dependable RF performance for telecom and microwave applications.
Impedance
Standard 50 Ohm impedance for precise impedance matching.
Frequency Range
Available in configurations supporting DC to 6 GHz, with specialized versions optimized for cellular frequency bands and telecom infrastructure.
Power Rating
Available in multiple power ratings including 2 W, 5 W, 10 W, 25 W, 50 W, 100 W, and higher depending on customer requirements.
VSWR
Low VSWR for excellent return loss and reduced signal reflections.
Connector Interface
Precision threaded 7/16 DIN Male and Female interfaces providing secure, vibration-resistant connections.
Materials
Manufactured using stainless steel or brass bodies, silver or gold-plated contacts, and PTFE dielectric materials.
Operating Temperature
Designed for reliable operation across a wide industrial temperature range.
Compliance
Manufactured according to international RF and microwave quality standards.
Applications of 7/16 DIN Terminations
Our 7/16 DIN Terminations are widely used in:
- Telecom base stations (BTS)
- 4G LTE networks
- 5G infrastructure
- Distributed Antenna Systems (DAS)
- In-Building Solutions (IBS)
- RF power amplifiers
- Microwave communication
- Broadcast transmitters
- Satellite communication
- RF laboratories
- Test & measurement equipment
- Antenna systems
- Defense communication
- Industrial wireless communication
- Outdoor RF installations
Key Performance Features
Selecting the right 7/16 DIN Termination ensures reliable RF system performance and equipment protection.
- Precision 50 Ohm impedance
- Low VSWR
- Excellent return loss
- Low Passive Intermodulation (Low PIM)
- High power handling capability
- Rugged threaded connector
- Weather-resistant construction
- Corrosion-resistant materials
- Superior mechanical durability
- Precision CNC machining
- Stable RF performance
- Long operational life
High-quality 7/16 DIN Terminations minimize signal reflections, improve RF system efficiency, protect expensive RF equipment, and provide dependable performance for telecom, broadcasting, aerospace, defense, and industrial communication systems.
Types of 7/16 DIN Terminations
7/16 DIN Male RF Termination
Designed to terminate female 7/16 DIN RF ports while maintaining accurate impedance matching.
7/16 DIN Female RF Termination
Used to terminate male 7/16 DIN connectors in RF communication systems.
Low PIM 7/16 DIN Termination
Designed specifically for modern cellular networks requiring extremely low passive intermodulation.
High Power 7/16 DIN Termination
Suitable for high-power RF transmitters, base stations, and broadcast systems.
Precision RF Termination
Engineered for laboratory-grade RF measurements and microwave testing applications.
Technical Specifications
Our 7/16 DIN Terminations are designed to deliver dependable RF performance for telecom and microwave applications.
Impedance
Standard 50 Ohm impedance for precise impedance matching.
Frequency Range
Available in configurations supporting DC to 6 GHz, with specialized versions optimized for cellular frequency bands and telecom infrastructure.
Power Rating
Available in multiple power ratings including 2 W, 5 W, 10 W, 25 W, 50 W, 100 W, and higher depending on customer requirements.
VSWR
Low VSWR for excellent return loss and reduced signal reflections.
Connector Interface
Precision threaded 7/16 DIN Male and Female interfaces providing secure, vibration-resistant connections.
Materials
Manufactured using stainless steel or brass bodies, silver or gold-plated contacts, and PTFE dielectric materials.
Operating Temperature
Designed for reliable operation across a wide industrial temperature range.
Compliance
Manufactured according to international RF and microwave quality standards.
Product Specifications
| Product Type | Impedance | Frequency Range | Application |
|---|---|---|---|
| 7/16 DIN Male RF Termination | 50 Ohm | DC to 6 GHz | Terminate Female RF Ports |
| 7/16 DIN Female RF Termination | 50 Ohm | DC to 6 GHz | Terminate Male RF Ports |
| 7/16 DIN Low PIM Termination | 50 Ohm | DC to 6 GHz | 4G & 5G Base Stations |
| 7/16 DIN High Power Termination | 50 Ohm | DC to 6 GHz | High Power RF Systems |
| 7/16 DIN Precision Termination | 50 Ohm | DC to 6 GHz | Vector Network Analyzer (VNA) |
| 7/16 DIN 2 Watt Termination | 50 Ohm | DC to 6 GHz | RF Testing |
| 7/16 DIN 10 Watt Termination | 50 Ohm | DC to 6 GHz | Telecommunication Systems |
| 7/16 DIN RF Dummy Load | 50 Ohm | DC to 6 GHz | Signal Reflection Control |
| 7/16 DIN Precision Dummy Load | 50 Ohm | DC to 6 GHz | RF Calibration |
| 7/16 DIN Test Port Termination | 50 Ohm | DC to 6 GHz | Microwave Communication |
Why Choose us
Precise Signal Control
Our 7/16 DIN Terminations are manufactured using advanced machining technology to provide exceptional RF performance and dependable signal termination.
High Power & Low PIM Performance
Designed for modern telecom infrastructure, our terminations support high-power RF applications while maintaining excellent passive intermodulation characteristics.
Low VSWR & Excellent Return Loss
Engineered to minimize signal reflections while maintaining maximum RF transmission efficiency.
Manufactured in India
All our 7/16 DIN Terminations are manufactured in India using premium materials, precision engineering, and strict quality control procedures to ensure reliable long-term performance.
Frequently Asked Questions
A 7/16 DIN Termination is an RF load used to terminate unused RF ports while maintaining accurate 50 Ohm impedance and preventing signal reflections.
They are manufactured with a standard 50 Ohm impedance.
Most standard models support frequencies from DC to 6 GHz, while specialized versions are available for specific telecom applications.
Power ratings include 2 W, 5 W, 10 W, 25 W, 50 W, 100 W, and higher depending on customer requirements.
They are widely used in telecom base stations, DAS, IBS, RF laboratories, broadcasting, microwave communication, and antenna systems.
Low Passive Intermodulation (Low PIM) minimizes unwanted signal distortion in high-power cellular communication systems, making it essential for modern 4G and 5G networks.
Yes. Their rugged threaded coupling and weather-resistant construction make them ideal for outdoor telecom infrastructure.
Yes. SRFS Teleinfra manufactures customized RF terminations with different power ratings, connector genders, and application-specific designs.
Yes. All our 7/16 DIN Terminations are manufactured in India using premium raw materials and advanced manufacturing technology.
SRFS Teleinfra offers precision-engineered 7/16 DIN Terminations with excellent RF performance, customized solutions, stringent quality control, competitive pricing, fast delivery, and expert technical support.
